ERV Air Ventilation System wall mounted easy installation

Short Description:

MODEL NO. ADA803
Product  Weight (kgs) 10.00
Product Size (mm) 450*150*330
Brand airdow/ OEM
Color White;Silvler;Gray
Housing Metal
Type Wall Mounted
Application Home;Office;Living Room;Conference Room;Hotel;School;Hospital
Rated Power (W) 15
Rated  Voltage (V) 110~120V/220~240V
Effective  area (m2) 10-20m2
Air flow (m3/h) 30
CADR (m3/h)
Noise  Level (dB) ≤58

Product Detail

Product Tags

Technical Data

MODEL NO. ADA803
Product  Weight (kgs) 10.00
Product Size (mm) 450*150*330
Brand airdow/ OEM
Color White;Silvler;Gray
Housing Metal
Type Wall Mounted
Application Home;Office;Living Room;Conference Room;Hotel;School;Hospital
Rated Power (W) 15
Rated  Voltage (V) 110~120V/220~240V
Effective  area (m2) 10-20m2
Air flow (m3/h) 30
CADR (m3/h)
Noise  Level (dB) ≤58

Product Features

★ Air purification:Originated in Sweden, a creative technique of air purifying with efficiency up to 95%, which purifies incoming and ensure clean air indoors.
★ Cool & heat recovery: Europen ERV(Energy Recovery Ventilators ) cooling & heating technology is adopted to retain the energy of output air in the exchanger and inject fresh air to keep the consistent temperature. It works like air conditioner but it is superior as an energy-saver. Moreover, The two heaters in the unit can sense the temperature of incoming air and automatically heat it when its temperature is low.
★ Environment-friendliness: Its withdrawal ratio of cool and heat reaches not less than 82% and takes lead in the market of 70% ratio in common. It contributes to the environment protection and avails users of more economic and comfortable living environment.
★ Ultra-low noise level:Its fan motor, possessing of perfect structure and muffler technology, works hardly with noise.
★ Easy installation:Unique and creative rear installation. Flexible and suitable in both new and present rooms. Available installation at any time. Convenient and safe to use.
★ With remote control.

Product Detail

ERV Air Ventilator With Purification And Easy Installation

ADA803 is a ERV ventilation system with air purification filtration. The ESP module designed in Sweden, a creative technique of air purifying with efficiency up to 95%, which purifies incoming and ensure clean air indoors.

How it works

Output of Indoor Stale Air:
1. Only top fan works and withdraws indoor Stale air from the inlet at the bottom.
2. Energy of incoming air is retained in the exchanger by cooling & heating exchange.
3. Stale air is emitted from the outlet at the back through fan.
Input of Outdoor Fresh Air:
1.Only below fan works and withdraws outdoor fresh air from the inlet at the back.
2.Incoming air is purified through ESP cell.
3.Energy of clean air is attained through cooling & heating exchanger to keep the consistent temperature.
4.Heaters on both sides will automatically work to heat the air in low temperature.
5.Clean air is inputted from the outlet at the front.

Explosive View

Details

Packing& Delivery

Box  Size (mm) 635*435*335
CTN SIZE (mm) 635*435*335
G.W./CTN (KGS) 12
Qty./CTN (SETS) 1
Qty./20'FT (SETS) 315
Qty./40'FT (SETS) 630
Qty./40'HQ (SETS) 720
MOQ 100
